parameters
| NO | Descriptiom | Parameter |
| 1 | Woking area | 200x6000mm |
| 2 | Control System | Cypcut controller system |
| 3 | Laser head | WSX brand cutting head |
| 4 | Guide rail | Taiwan HIWIN Linear guide rail 25mm |
| 5 | Transmission | Taiwan TBI ball screw transmission |
| 6 | Electronic Components | French Schneider |
| 7 | Motor | all axis Panasonic servo motor |
| 8 | Max Cutting Speed | 35m/min |
| 9 | X axis max speed | 65m/min |
| 10 | Y axis max speed | 100m/min |
| 11 | Z axis max speed | 30m/min |
| 12 | X axis max acceleration | 1G |
| 13 | Y axis max acceleretion | 1G |
| 14 | Cooling Way | Water Cooling CW6000 |
| 15 | Min Line width | 0.1mm |
| 16 | Power Requirements | 380V,50/60HZ,16A |
| 17 | Continuous Working Time | 24Hours |
Basic Features
Clamp Design
It adopts an electric clamp design on both sides and it can modulate the center automatically. The diagonal adjustable range is 20-200mm(Optional:300mm).
Raycus laser generator
Raycus has an efficient and professional R&D and production team. The single module CW fiber laser series not only can meet diversified demands of customers to the greatest extent, but also provide personal customization service. Now laser output connector is QBH, with multiple control modes.
WSX brand cutting head
HIWIN Guide rails
Rail works with slider, drive the machine move, with good bearing capacity.
Japanese Yaskawa Servo Motor
Y axis 1.8KW, X axis 850W. Faster speed with signal feedback. Low heat radiation. Run smoothly at ultra-low speed.Reduce the vibration, avoid oscillation. Efficient torque enhancement.
Options
More powerful Raycus laser
We supply laser power from 0.5KW to 12KW to meet different customers'cutting demands.
IPG Laser Generator
IPG Laser Generator is available from 1.0KW to 12KW. It has better performance in cutting aluminum,brass and cooper.
