parameters
| No | Deacription | Parameter |
| 1 | Rotary axis | 1200*1200*600mm, C axis: ±360°, Aaxis: ±110° |
| 2 | Framework | Cast Steel Structure |
| 3 | Spindle | Italian Hiteco 12kw 5axis spindle |
| 4 | Rotating Speed | 6000-24000rpm/min |
| 5 | Tool Magazine | Disc-type ATC (with 8 tools) |
| 6 | Working Mode | Yaskawa Servo motor |
| 7 | X,Z axis transmission | Germany Rexroth linear guide rails H30, Germany rack |
| 8 | Y axis transmission | TAIWAN PMI ballscrew |
| 9 | Repositioning Accuracy | ± 0.03mm |
| 10 | Dictate Formate | G code,*uoo,*mmg,*plt |
| 11 | Interface | USB |
| 12 | Control System | Taiwan Syntec controller |
| 13 | Support Software | UG software |
| 14 | Packaging | Standard Plywood Case for Export |
Basic Features
DISC type ATC device
Fast response ,with 8-10 pieces auto tool changer ,high working efficiency .
Italian Hiteco 12kw 5axis spindle
Smooth body, not easy to rust;powerful and longer lifetime.Independent research and development, rational design.
Syntec controller 21MA
The system stability is very good, the man-machine operation is friendly, easy to learn and operation, powerful function
HIWIN Guide rails
Rail works with slider ,drive the machine move ,with good bearing capacity.
JAPANESE YASKAWAservo motor
Faster speed with signal feedback .Low heat radiation .Run smoothly at ultra-low speed.Reduce the vibration ,avoid oscillation .Efficient torque enhancement .
Options
Oil free vacuum pump
Continuous operation, no oil, low noise, low vibration, Environmentally friendly and low energy consumption
Mist spray cooling system
Reduce the heat of material and workingtool bits .suitable for metal processing .
applications
1) Mould: wood,wax, wood, gypsum, foams, wax
